Description
Driver | 12″ front firing driver 12” side radiating passive radiators |
---|---|
Amplifier Class D | 800 watt dynamic 400 watt RMS |
Overall Frequency Response: (± 3 dB) | 25 Hz – 180 Hz |
Overall Frequency Response: (± 10 dB) | 22 Hz – 220 Hz |
Low Pass Crossover | 50 Hz to 180 Hz (12 dB/Octave) |
Phase | 0 / 180 degrees |
Cabinet Design | 22 mm MDF |
Magnet Structure | Dual ferrite magnet motor |
Woofer | 12” high excursion double vented basket driver with pp Membrane and convex cone |
Voice Coil | Four Layer 2,5″ / 63 mm voice coil |
Input | Gold plated Stereo/LFE RCA, Nickel plated High level in |
Output | Gold plated Stereo/ LFE RCA |
Power Selector | Off / Auto / On |
Finishes | Flat matte black paint |
Dimensions (W/H/D) (includes feet and connectors) | 41 cm x 48 cm x 41 cm |
Weight (approx) | 25 kg |
