Package Includes
Krix Harmonix (Pair)
Krix Vortex (Centre)
Krix Equinox (Rear's)
Krix Volcanix Subwoofer
Price is based on Black Woodgrain
Krix is an Australian owned and operated company based in Adelaide, with more than 45 years experience they mean business when it comes to theatre - that's why they do over 80% of Australian commercial cinemas!
This packages packs some serious punch, you will not be let down.
Harmonix
Frequency Range
35Hz-40kHz in room response
Power Handling
50 – 250 Watts RMS recommended amplifier power
Sensitivity
90dB for 2.83 volts at 1 metre
Impedance
Nominally 6 Ohms (minimum 3.1 Ohms)
Configuration
3-way
Enclosure Type
Dual chambers – sealed midrange chamber with bass reflex main chamber. Front vented with internal and external flaring
Dimensions
1040mm high x 220mm wide x 350mm deep (including feet)
Low Frequency Drivers
2 x nominal 165mm (6½”) laminated polypropylene cones. 33mm (1¼”) voice coil wound on high powered aluminium former, with ventilated spider and aluminium flux stabilization ring for low distortion
Mid Frequency Driver
1 x nominal 130mm (5″) coated paper cone. 26mm (1″) voice coil wound on high powered aluminium former, using copper shorting ring and oversized magnet for lower distortion
High Frequency Driver
25mm (1″) dual concentric diaphragm with wave-guide centre plug for controlled directivity. Non-reflective dual chambered magnet structure with copper shorting ring to lower distortion
Input Terminals
Dual gold plated bi-wire binding posts (bi-wireable, bi-ampable)
Weight
28kg each
Vortex
Frequency Range
35Hz-40kHz in room response
Power Handling
50 – 250 Watts RMS recommended amplifier power
Sensitivity
91dB for 2.83 volts at 1 metre
Impedance
Nominally 6 Ohms (minimum 3 Ohms)
Configuration
3-way
Enclosure Type
Dual chambers – sealed midrange chamber with bass reflex main chamber. Front vented with internal and external flaring
Dimensions
230mm high x 725mm wide x 370mm deep
Low Frequency Drivers
2 x nominal 165mm (6½”) laminated polypropylene cones. 33mm (1¼”) voice coil wound on high powered aluminium former, with ventilated spider and aluminium flux stabilization ring for low distortion
Mid Frequency Driver
1 x nominal 130mm (5″) coated paper cone. 26mm (1″) voice coil wound on high powered aluminium former, using copper shorting ring and oversized magnet for lower distortion
High Frequency Driver
25mm (1″) dual concentric diaphragm with wave-guide centre plug for controlled directivity. Non-reflective dual chambered magnet structure with copper shorting ring to lower distortion
Input Terminals
Dual gold plated bi-wire binding posts (bi-wireable, bi-ampable)
Weight
24kg each
Equinox
Frequency Range
45Hz-40kHz in room response
Power Handling
20 – 120 Watts RMS recommended amplifier power
Sensitivity
88dB for 2.83 volts at 1 metre
Impedance
Nominally 6 Ohms (minimum 3.6 Ohms)
Configuration
2-way
Enclosure Type
Bass reflex, rear vented
Dimensions
295mm high x 175mm wide x 235mm deep
Low Frequency Driver
Cast aluminium basket with a nominal 130mm (5″) doped curvilinear paper cone. 30mm (1.2″) vented magnet voice coil wound on high temperature kapton former, with copper shorting ring
High Frequency Driver
26mm (1″) dual concentric diaphragm with wave-guide centre plug for controlled directivity. Non-reflective dual chambered magnet structure with copper shorting ring to lower distortion
Input Terminals
Gold plated binding posts
Weight
6kg each
Volcanix
Frequency Range
20Hz-200Hz in room response
Amplifier Power
450 Watts RMS, 900 Watts maximum instantaneous power
Output
123dB maximum SPL in room response
Inputs
Stereo line level RCA. High level inputs
Enclosure Type
Bass reflex, front vented
Dimensions
450mm high x 360mm wide x 410mm deep
Low Frequency Driver
Nominal 275mm (11”) diameter doped paper cone driver, 50mm (2″) voice coil wound on high powered Kapton former, with vented magnet assembly
Power On/Off
Adjustable Auto/Always On. Adjustable ‘Auto Sensitivity’ setting and 12V trigger setting
Phase Select
0º to 180º (relative to input signal)
Low Pass Filter
50Hz-195Hz or bypass
Weight
18kg each
After another finish? Get in touch with us!
07-3552-7000
sales@livingsound.com.au
Please note Tektonix is shown, this has been discontinued and you will be provided with the better Volcanix Sub.
