Eversolo

Eversolo DAC-Z6

$679.00$799.00
  • Eversolo DAC-Z6
  • Eversolo DAC-Z6
  • Eversolo DAC-Z6
  • Eversolo DAC-Z6
1

Free shipping Australia-wide for orders over $500


Putting together a custom system? Click 'Add to quote' below, add any other products you’re interested in, and get a customised quote.

Description



Model EverSolo DAC-Z6 Display Screen 3-inch LCD screen Chassis Aluminum Alloy DAC Audio ES 9068*2 Audio Processor XMOS XU316 OPA Chip RT 6863*6 Power Supply high quality switching power supply with low noise Bluetooth Audio Input Qualcomm QCC5125 Bluetooth module, BT5.0 Support SBC/AAC/aptX/aptX LL/aptX HD/LDAC Bluetooth protocol USB-B DAC Input Compatible with Windows (7, 10), Mac, Android and IOS Up to stereo DSD512, PCM 768KHz 32Bit, MQA USB-C DAC Input Compatible with Windows (7, 10), Mac, Android and IOS Up to stereo DSD512, PCM 768KHz 32Bit, MQA OPTICAL Audio Input Up to stereo PCM 192Khz 24Bit, DSD64 Dop,MQA COAXIAL Audio Input Up to stereo PCM 192Khz 24Bit, DSD64 Dop,MQA Analog Audio Output Preamp output: XLR(balanced)+RCA
Headphone output: 6.3mm single-ended USB Port USB2.0*1（only for firmware upgrade） Control Methods Remote control, Mobile APP control, Knob control Headphone Impedance 16-300Ω (low gain mode:16-32Ω/high gain mode:32-300Ω) XLR Audio Output Output Level(Vrms)：4.1Vrms@0dBFS
THD+N@A-wt：0.000094%@1kHz（-120dB@1kHz）
THD+N@No-wt：0.000117%@1kHz（-118dB@1kHz）
Noise@No-wt ：<3uVrms
SNR)@No-wt：125@1kHz
frequency response：20Hz-20kHz(±0.15dB)
CROSSTALK：-123dB@1kHz
DNR)@No-wt：125dB@1kHz RCA Audio Output Output Level(Vrms)：2.1Vrms@0dBFS
THD+N@A-wt：0.000116%@1kHz(-118dB@1kHz)
THD+N@No-wt：0.000138%@1kHz(-117dB@1kHz)
Noise@No-wt ：<2.5uVrms
SNR)@No-wt：21dB@1kHz
frequency response：20Hz-20kHz(±0.15dB)
CROSSTALK：-118dB@1kHz
DNR)@No-wt：121dB@1kHz Headphone
(low gain mode) Output Level(Vrms)：1.2Vrms@0dBFS
Max Power：： 45 mW@32Ω
THD+N@A-wt：0.00028%@1kHz(-111dB@1kHz)
THD+N@No-wt：0.00031%@1kHz(-110dB@1kHz)
Noise@No-wt ：<3.5uVrms
SNR)@No-wt：114dB@1kHz
frequency response：20Hz-20kHz(±0.15dB)
DNR)@No-wt：114dB@1kHz Headphone
(high gain mode) Output Level(Vrms)：2.8Vrms@0dBFS
Max Power： 26 mW@300Ω
THD+N@A-wt：0.00014%@1kHz(-117dB@1kHz)
THD+N@No-wt：0.00016%@1kHz(-116dB@1kHz)
Noise@No-wt ：<3.5uVrms
SNR)@No-wt：121dB@1kHz
frequency response：20Hz-20kHz(±0.15dB)
DNR)@No-wt：121dB@1kHz Power Input AC 110~240V 50/60Hz Rated power 9W Product Dimensions 270mm(W) * 187mm(D)* 50mm(H) Accessories Remote control*1, Power cable*1, User manual*1
